Bertram 510 Convertible

2007 • 51' (15.54 m) • Power

$499,999 USD

FOR SALE is this beautiful and elegant 2007 Bertram 51' Convertible!

A true must see!!

  • Very well kept and maintained
  • Equipped with Twin V-10 M.A.N. engines
  • ZF Transmissions with Straight Shaft Drive

Please feel free to ask any questions about this vessel. Great opportunity!!!


Vessel Information

Builder: Bertram
Model: 510 Convertible
Model Year: 2007
Category: Power
Sub Category: Convertible Boats, Sports Fishing Boats
Condition: Used

LOA: 51' (15.54 m)
Engine Info: MAN V-10 Direct diesel 1100|horsepower Inboard 1900 Port

Location: Cartagena, CO
City: Cartagena
Country: CO


Overall Length (w/bow pulpit): 54 Feet 10 inches

Hull Length: 51 Feet 05 Inches Beam: 16 Feet 02 Inches Draft: 5 Feet

Height Above Waterline: 14 Feet

Cockpit Square Feet: 168 Sq.ft.

Displacement: 65,489 lbs (29.7 ton)


Cabin Sole: Carpet throughout except for wood panel sole at the Galley, Dinette and Head compartments.

Window Covering: Wooden blinds over the Main Salon windows


Master's Stateroom: Port/Owner's Stateroom provides sleeping for two adults on a full berth (w/storage drawers below), a dual hanging locker, LCD TV, AM/FM radio and CD/DVD player and a full enclosed head compartment (forward). VIP's Stateroom: Forward/VIP's Stateroom provides sleeping for two adults on a full berth, a dual hanging locker, LCD TV, AM/FM radio and CD/DVD player, access to the anchor chain locker (forward) and a fully enclosed head compartment (aft to starboard). Guest's Stateroom: Starboard/Guest room provides sleeping for two adults on two single berths (w/storage drawers below), a hanging locker, LCD TV and AM/FM radio and CD/DVD player.


LCD TV: Manufacturer: Sharp (4 units). Model; Aquos.

DVD Player: Manufacturer: Philips. Model: DV 4060

AM/FM Radio & CD/DVD Player: Manufacturer: Sony. Model: MEX-DV1000. Located in Master Stateroom. AM/FM Radio & CD/DVD Player: Manufacturer: Sony. Model: MEX-DV1500U. Located in VIP Stateroom.

AM/FM Radio & CD/DVD Player: Manufacturer: Sony. Model: MEX-DV900. Located in Guest Stateroom.

Music Entertainment System: Manufacturer: Bose. Model: Lifestyle

Interior Speakers: Total of six (6) interior speakers at the staterooms. Additonally, five (5) dual Bose interior speakers at the Main Salon.

VHF: Manufacturer: ICOM. Model: IC-M602

VHF: Manufacturer: ICOM. Model: IC-M604

Autopilot: Manufacturer: Simrad. Model: AP25

Engine Digital Displays: Manufacturer: M.A.N. (2 units). Model: MMDS-CLC 6.3

GPS/Radar/Chart/Navigation System: Manufacturer: Raymarine (2 units). Model: E120.

GPS/Chart/Navigation System: Manufacturer: Northstar. Model: 6100i.

Digital Speed/Depthfinder: Manufacturer: Furuno. Model: RD-30

Compass: Manufacturer: Ritchie.

AM/FM Radio & CD Player: Manufacturer: Clarion. Model: CMD-5

Exterior Speakers: Total of four (4) speakers

Antennas: Total of seven (7) antennas mounted at the Flybridge hardtop.


Heads: Two (2) heads located at the Master and VIP Staterooms.

Showers: Head compartments featured acrylic countertops and sinks, faucets, electric heads, vinyl wall covers, wood panel soles and enclosed showers

Furniture: Main Salon features an L-shaped sofa (w/storage below) and a wood coffee table. Dinette features an L-shaped bench (w/storage below), an acrylic dinette table and overhead rod storage.

Washer: Manufacturer: Malber. Model: P21

Dryer: Manufacturer: Malber. Model: TD700

Central Vacuum Cleaner: Manufacturer: Walvac


Refrigerator:Manufacturer: Sub-Zero. Model: 700BR.

Freezer: Manufacturer: Sub-Zero Model: 700BF.

Cooktop: Manufacturer: Kenyon. Type: Electric Range. Model: Three (3) Burners.

Microwave: Manufacturer: Panasonic. Model: 1200W

Automatic Ice Maker: Manufacturer: U-Line


Cockpit Shower: Hot and Cold

Cockpit Table

Fiberglass swim platform

Swimming Ladder


Manufacturer: ZF (Zahnradfabrik Friedrichshafen)

Model Number: Port: ZF 550 A / Starboard: ZF 550 A

Type: Reversing clutch type with reduction gears

Drive Type: Straight

Gear Ratio: Transmission tag states 1.97:1

Controls: ZF electronic single lever controls

Propeller Shafts: Size: 3 inches Material: Stainless Steel

Stuffing Boxes: Dripless Type System


Voltage: Lead acid battery powered 12 and 24 volt system

Batteries: Type: Marine

Banks: Four (4) 8D batteries located aft engine room to port (2) and starboard (2). Two (2) 12V batteries located aft engine room to starboard

Main Battery Switches: Two (2) Guest battery switches located mid-engine room to port. One (1) Blue Seas System battery switch.

Main Breakers: Two (2) main breakers for 24V DC at the main electrical panel (aft main salon to starboard). Two (2) main breakers for 24V DC at the secondary electrical panel. Two (2) main breakers for 12V DC and two (2) main breakers for 24V DC at secondary electrical panel.

Panel: Overcurrent Protection: Circuit breakers. Twenty-two (22) breakers for 24V at the main electrical panel. Fourteen (14) branch breakers for 24V at secondary electrical panel. Ten (10) 12V breakers and fourteen (14) 24V breakers at the secondary electrical panel.

Charging Systems: Alternators on main diesel engines and diesel generator.

Battery Chargers: Manufacturer: Mastervolt (2 units). Model: MASS24150

Battery Equalizer: Manufacturer: Vanner. Model: Voltmaster. Type: 60 Amps

Shore Power Inlet: Number: Two (2). Location: Cockpit (forward to port and starboard). Weather Protected: Standard Hubble Stainless Steel w/Cap. Rating: 125/250 Volts, 50 Amps

Shore Power: Cord: Two (2) Approx. 50" long. Cable Master: Glendinning

AC Source Selector Switch: Two (2) 70A generator selector switches located at Main Salon

Main Breakers: Two (2). Rating: 50 Amps

Branch Breakers: Sixteen (16) breakers for 120V and twelve (12) breakers for 240V at the main electrical panel. Sixteen (16) breakers for 120V and four (4) breakers for 240V at the secondary electrical panel.

Circuit Load Monitors: Two (2) AC voltmeters and two (2) AC ammeters at he main electrical panel.


2x Kohler

Model Number: 15.5 EOZD

Number of Cylinders: Three (3) In-line

Fuel Filter: Remote Racor 500 MA fuel filter/water separator

Exhaust System: FRP exhaust muffler, wet exhaust




Fuel Type: Diesel

Material/Number of Tanks: Aluminum / two (2)

Tanks Capacity: 1,040 gallons

Location: Engine Room (forward)

Shut-Off Valves: Forward main engines at fuel manifold valve system

Fuel Filters: Four (4) remote mounted Racor 75/1000MAX fuel filters. Also engine mounted spin on/off


Potable Water

Storage Tanks: One (1) main ship tank

Capacity: 185 gallons ships water

Pressure Pump: Jet type fresh water pump located in the engine room

Hot Water System

Manufacturer: Seaward Water Heater

Model: S1250

Capacity: Approx. 30 gallons

Sea Water Desalinator System

Manufacturer: Sea Recovery

Model: Aqua Whisper

Type: Reverse Osmosis / 220 AC High Pressure System


Black Water

Number of Heads: Two (2)

Manufacturer: Tecma Marine

Grey Water

Basins and Showers

Sump Pump: One sump tank Attwood Sahara S750 sump pump


Type: Hydraulic

Manufacturer: Hynautic Inc.

Rudder Stock: Stainless steel rudder stock

Rudder Shaft Packing: Bronze hex nut type packing gland


Anchors: Number; One (1). Type: Plow Anchor

Line/Rode Construction: Approx. 200' of 5/8" marine graded lines in locker.

Chain: Approx. 10' of G5 5/16" BBB type chain in locker.

Windlass: Manufacturer: Lewmar Anchor Windlass


Auxiliary Safety Equipment

Auxiliary Craft(Tender): Name: T/T Andiamo. Manufacturer: Nautica International. Model: RIB 11. Outboard Motor: Sngle Yamaha, 4 Stroke, 40 HP. Model: F40 TLR. Date Built: 01/2006

Searchlight: One ACR Electronics dual beam searchlight

Bilge Pumps

Number: Six (6) bilge pumps

Type: Rule Submersible

Model: 2000


Air Conditioning and Heating

Type: Split System

Manufacturer: Cruisair

Number of units: Three (3) compressors

Control: Three (3) Cruisair air conditioning digital controls at main salon, forward stateroom and port stateroom.

Raw water cooling pump: 110 volt electric pumps systems are equipped with seacocks and Perko sea strainers assemblies.


Rod Holders: Total of ten (10) rod holders: four (4) gunwale mounted and six (6) uppers at the flybridge railing.

Outriggers: Triple spreader outriggers (by Pipe Welders)

Rod Storage: An overhead rod storage compartment located at the Dinette.

Fighting Chair: Teak seat, large

Bait Freezer: One custom bait freezer locates forward cockpit to port.

Wash Down System: One raw water wash down at the cockpit. One fresh water wash down forward cockpit to starboard.

Live Bait Well: One live bait well located forward cockpit to starboard.

Tackle Center: One tackle center located forward at the cockpit.

Fish Boxes: One large FRP fish box (w/tuna tubes within) located below the cockpit deck. One FRP fish box (w/output for Eskimo ice machine) located inboard transom.

Spreader/Flood Lights: Four (4) spreader/flood lights mounted on the flybridge hardtop.


Propellers: Number of blades: Five (5). Material: Nibral/Bronze

Propeller Shafts: Diameter: 3 Inches. Material: Stainless Steel

Underwater Lights: Two (2) Deep Sea underwater lights located at the transom


The company offers the details of this vessel in good faith but cannot guarantee or warrant the accuracy of this information nor warrant the condition of the vessel. A buyer should instruct his agents, or his surveyors, to investigate such details as the buyer desires validated. This vessel is offered subject to prior sale, price change, or withdrawal without notice.
