2027 Johnson Skylounge Motor Yacht

1.  MAIN DECK-TEAK2.  STAINLESS STEEL INTEGRAL ROLLERS & CHAIN STOPPER       FOR ANCHOR CHAIN3.  250 FEET GALVANIZED CHAIN (3/8”)4.  MAXWELL HYDRAULIC RC12-12 WINDLASS5.  STAINLESS STEEL 120 LB ANCHOR (SINGLE)6.  HEAVY DUTY 316# S/S HANDRAIL & STANCHIONS7.  HEAVY DUTY 316# S/S CLEATS AND FAIRLEADS8.  MEDIUM TINTED SAFETY GLASS9.  PNEUMATIC STAINLESS STEEL SALOON SLIDING DOOR WITH PUSH BUTTON AND SAFETY SENSORS10. STAINLESS STEEL PORT LIGHTS11. S/S RUB RAIL W/RUBBER INSERT AROUND HULL & DECK JOINT12. STERN CAPSTAN 24V x 2 SETS - MAXWELL VC250013. AFT DECK SEATING BUILT IN W/ CUSHIONS14. AFT DECK TABLE15. LED LOW LEVEL COURTESY LIGHTS ON SIDE DECK16. LED LOW LEVEL COURTESY LIGHTS ON AFT DECK17. STAIRS TO FLYBRIDGE18. LARGE TEAK INLAY SWIM PLATFORM WITH STAIRWAY TO AFT DECK19. HOT & COLD TRANSOM SHOWER20. S/S SWIM LADDER21. SUN BATHING/SEATING AREA ON FWD DECK22. WATER FILL DECK FITTING23. DIESEL FILL DECK FITTING24. FLOJET 4325-343L DECK WASHDOWN PUMP25. FLOODLIGHT FOR COCKPIT - LED26. CANVAS COVERS FOR EXTERIOR SETTEE AND TABLES27. WATER RESISTANT SUN PAD ON BOW WITH U-SHAPED SEATING28. WHITE GEL COAT THROUGHOUT HULL

1.   5 BLADE BRONZE PROPELLERS2.   BRONZE P-BRACKETS3.   S/S AQUATECH 22HS S3" DIAMETER SHAFTS4.   SHAFT SEAL AND SHAFT LOG - TIDES RUDDER SEAL 3”; TIDES SHAFT SEAL 3”5.   ANTI-FOULING BOTTOM PAINT      SEA HAWK PRIMER SYSTEMS TUFF STUFF 1284 GREY OR 1285 WHITE      SEA HAWK SELF-POLISHING COPOLYMER ANTIFOULING CUKOTE 3445    BLACK  OR 3430 DARK BLUE6.   BOOT TOP STRIPE SIZE 3”; COLOR: BLACK, BLUE OR RED7.   HUMPHREE INTERCEPTOR TRIM TABS H750 x 28.   FULL CATHODIC BONDING SYSTEM TO ZINC ANODES9.   SEAWATER STRAINERS FOR ENGINES, GENSET AND AIR-CONDITIONING10. SEACOCKS ON ALL UNDERWATER FITTINGS11. UNDERWATER EXHAUST SYSTEM

1.  FLOOR     HELM AREA: TEAK     LOUNGE AREA: CARPET2.  INSTRUMENT CONSOLE3.  LEATHER SOFA & COFFEE TABLE4.  U-LINE COMBO REFRIGERATOR/ICE MAKER5. GARMIN    GPSMAP® 8617 17" FULLY-INTEGRATED MULTI-TOUCH MFD x 2    GMI 20 MARINE INSTRUMENT DISPLAY x 1   GMR FANTOM™ 4"/40w/72NM, SOLID-STATE, OPEN-ARRAY RADAR X1    GARMIN VHF 210 MARINE RADIO x 1    GARMIN AIS 600 CLASS B TRANSCEIVER x 1    GHP™ 20 MARINE AUTOPILOT SYSTEM WITH SMARTPUMP x 1    GARMIN GSD 25 MARINE NETWORK SOUNDER 2KW x 16.  RUDDER INDICATOR7.  MAGNETIC COMPASS8.  S/S GUARD RAILS AND GRAB RAILS9. SPEICH NAUTIC TYPE LP WIPERS x 210. LOW LEVEL COURTESY LIGHTS 24V11. SEARCH LIGHT - PAR 60010-2024 24V12. AIR HORN - BUELL13. BESENZONI P217 24V HELM SEAT x 214. S/S STEERING WHEEL15. POP-UP TV CABINET WITH VIZIO M322I-B1 32” 1080P LED LCD HDTV16. FUSION STEREO SYSTEM    SKYLOUNGE    MS-AV700I DVD / RECEIVER – WITH FUSION LINK.    MS-CL602 6” MARINE CEILING MOUNT SPEAKERS x 2    MS-BT200 BLUETOOTH ADAPTER MODULE FOR SIRIUS PORT    FLYBRIDGE AFT    MS-RA205 RECEIVER / MEDIA PLAYER WITH FULL IPOD / IPHONE CONTROL    MS-FR7021 7” 260 WATT SPEAKERS x 3 GRILLES INCL.    MS-BT200 BLUETOOTH ADAPTER MODULE FOR SIRIUS PORT17. APPLE TV18. CCTV SYSTEM WITH 4 CAMERAS      (ENGINE ROOM, SALOON DOOR, AFT DECK PORT & STBD)19. ONE SHIPSET LED NAVIGATION LIGHTS

1.  TWIN CATERPILLAR C-18 ACERT 1150HP ENGINES WITH ZF 550IV GEAR BOXES2.  ENGINE DUAL RACOR FILTERS3.  GENERATOR RACOR FILTER4.  SOUNDPROOFING THROUGHOUT ENGINE ROOM5.  WELL PLANNED, SPACIOUS E/R WITH DIAMOND PATTERN DECK PLATES6.  FUEL TANKS WITH BEP ELECTRIC SENDING UNITS7.  AUTOMATIC SEA-FIRE FIRE EXTINGUISHER8.  ENGINE ROOM AIR INTAKE SYSTEM9.  ENGINE ROOM AC FLOURESCENT LIGHTS & DC DOME LIGHTS10. HENDERSON BP0510 MANUAL BILGE PUMP11. HIGH VOLUME AC F.W. PRESSURE PUMP AND ONE 24V DC PUMP FOR BACK UP     ● HEADHUNTER MARCH 5 M5-115 AC PUMP     ● GROCO PSR 4000004-24 24V DC PUMP12. CHILLED WATER AIR CONDITIONING -       CRUISAIR AIR CONDITIONING W/48000 BTU COMPRESSOR x 213. SEA RECOVERY 700GPD WATER MAKER x 114. OIL CHANGING PUMP FOR ENGINES, GENERATOR AND CLUTCHES15. GENERATOR - ONAN MDKDS 29KW 60HZ x 116. WATER HEATERS - SEAWARD HF2250 20 GALLONS x 217. 600 GPD HEADHUNTER SEWAGE TREATMENT SYSTEM ADDED 9/1/23

1.   110V/220 AC ELECTRICAL SYSTEM2.   DC 24V SYSTEM3.   70’ GLENDINNING CABLE MASTER CM7 50A x 24.   BATTERY CHARGER FOR 24V CIRCUIT5.   BATTERY CHARGER FOR 12V CIRCUIT6.   ALTERNATOR SPLIT CHARGING SYSTEM7.   255AMP/HR GELL CELL SEALED BATTERIES FOR SHIP SERVICE x 48.   255AMP/HR GELL CELL SEALED BATTERIES FOR ENGINES x 49.   210AMP/HR GELL CELL SEALED BATTERIES FOR GENSET x 110.  AC SOCKETS THROUGHOUT THE BOAT11.  GFI PROTECTION FOR AC REQUIRED SOCKETS12.  BATTERY SELECTOR SWITCH13.  MAIN ELECTRICAL PANEL INCLUDES AC & DC CIRCUIT BREAKERS14.  AUTOMATIC ISOLATING & BOOSTER TRANSFORMER - 50AMP x 215.  ANTI ELECTROLYSIS BONDING SYSTEM16.  4KW INVERTER x 1

1. HOLDING TANK WITH MACERATOR PUMP2. HOLDING TANK LEVEL INDICATOR3. SUMP PUMP FOR SHOWERS4. MARINE GRADE LINES FOR FRESH WATER SYSTEM5. S/S WATER TANK WITH SENDING UNIT - 260 GALLONS6. ALUMINIUM FUEL TANK WITH SENDING UNIT - 920 GALLONS7. SIGHT GAUGES FOR FUEL AND WATER TANKS8. DOCKSIDE FRESH WATER INLET9. COLOR CODED PIPING FOR EASY IDENTIFICATION10. BRONZE INTAKE VALVES FOR ALL THRU-HULL FITTINGS11. MANIFOLD FOR OVERBOARD DISCHARGES TO MINIMIZE NUMBER OF      THRU-HULL FITTINGS12. SEALAND FRESH WATER VACUUM TOILET SYSTEM13. HIGH WATER BILGE ALARM X 6 AREAS14. RULE 3700 BILGE PUMPS 24V x 615. BOW & STERN HYDRAULIC THRUSTERS16. "AT REST" STABILIZERS

1.  INTERIOR JOINERY IN CHERRY AND IVORY LACQUER WITH ANDARI COLLECTION       OF UPHOLSTERY FABRICS2.  OWNERS CHOICE OF MARBLE SHOWER FLOOR AND MARBLE COUNTERTOPS

1.  SUB-ZERO ID-24R DRAWER TYPE REFRIGERATOR2.  SUB-ZERO ID-24FI DRAWER TYPE FREEZER3.  S/S SINK4.  HOT AND COLD WATER SYSTEM5.  FISHER & PAYKEL LATEST MODEL DISHWASHER x 16.  DOUBLE AC SOCKETS x 27.  CUPBOARD, DRAWERS AND STOWAGE8.  GE LATEST MODEL MICROWAVE W/EXTRACTOR FAN9.  GE LATEST MODELTRASH COMPACTOR10. TEAK SOLE11. MIELE LATEST MODEL 4 BURNER COOKTOP

1.   PNEUMATIC S/S SALOON SLIDING DOOR2.   VIZIO M471i-A2 47” TV3.   BOSE LIFESTYLE 535 SERIES III HOME THEATER SYSTEM4.   PIONEER BDP-160 BLU-RAY DISC PLAYER5.   APPLE TV6.   HIGH QUALITY LEATHER COUCH IN LOWER SALOON & DINING AREA7.   BLINDS, CURTAINS8.   LOW LEVEL LIGHTS 24V9.   CEILING LED LIGHTING 24V10.  COFFEE TABLE11.  INDIRECT LIGHTING12.  U-LINE LATEST MODEL WINE COOLER13.  SPLENDID LATEST MODEL WASHER14.  SPLENDID LATEST MODEL DRYER

1.  KING SIZE BERTH2.  STORAGE BENEATH3.  DRAWERS IN BASE OF BERTH4.  VANITY5.  LED CEILING LIGHTING 24V6.  CANTALUPI MILOS/CHROME/MATT NICKLE LED READING LIGHTS 110VAC x 27.  TWO LARGE RECTANGULAR PORTLIGHT WINDOWS ON EACH SIDE      W/CENTER PIECE OPENABLE8.  VIZIO M322I-B1 32" 1080P LED LCD HDTV9.  FUSION STEREO SYSTEM     MS-RA205 RECEIVER / MEDIA PLAYER WITH FULL IPOD / IPHONE CONTROL     MS-CL602 6” MARINE CEILING MOUNT SPEAKERS x 4     MS-BT200 BLUETOOTH ADAPTER MODULE FOR SIRIUS PORT10. SONY BDP-S360 BLU-RAY DISC PLAYER11. APPLE TV12. WALK-IN CLOSET

1.  SEALAND VACUUM TOILET (BONE COLOR)2.  WASH BASIN WITH MABLE COUNTERTOP3.  HOT & COLD WATER4.  FAUCET AND FITTINGS5.  DRESSING MIRROR AND MIRRORED CEILING6.  LACQUER FINISH ABOVE BASIN COUNTERTOP7.  VENEER FINISH BELOW BASIN COUNTERTOP8.  EXTRACTOR FAN9.  AC DOUBLE SOCKET WITH GFI10. LAQUER FINISH IN SHOWER AREA11. LED CEILING LIGHTS 24V12. MARBLE FLOOR

1.  DOUBLE BERTH2.  STORAGE BENEATH3.  DRAWERS IN BASE OF BERTH4.  WALK-IN CLOSET5.  VIZIO M322I-B1 32" 1080P LED LCD HDTV6.  QUICK MAYA30 READING LIGHTS 24V x 27.  LED CEILING LIGHTS 24V8.  FUSION STEREO SYSTEM     MS-AV700I DVD / RECEIVER – WITH FUSION LINK.     MS-CL602 6” MARINE CEILING MOUNT SPEAKERS x 4     MS-BT200 BLUETOOTH ADAPTER MODULE FOR SIRIUS PORT9.  APPLE TV10. AC DOUBLE SOCKETS11. ESCAPE HATCH12. ONE LARGE RECTANGULAR PORTLIGHT WINDOW EACH SIDE         WITH CENTER PIECE OPENABLE

1.  SEALAND VACUUM TOILET (BONE COLOR)2.  WASH BASIN WITH MABLE COUNTERTOP3.  HOT & COLD WATER4.  FAUCET AND FITTINGS5.  DRESSING MIRROR AND MIRRORED CEILING6.  LACQUER FINISH ABOVE BASIN COUNTERTOP7.  VENEER FINISH BELOW BASIN COUNTERTOP8.  EXTRACTOR FAN9.  AC DOUBLE SOCKET WITH GFI10. SHOWER AREA WITH LACQUER FINISH11. LED CEILING LIGHTS 24V12. MARBLE FLOOR

1.  ONE DOUBLE BERTH2.  UNDER BERTH STORAGE3.  QUICK MAYA30 READING LIGHTS 24V x 24.  LED CEILING LIGHTS 24V x 25.  HANGING LOCKER6.  VIZIO M322I-B1 32” 1080P LED LCD HDTV7.  FUSION STEREO SYSTEM     MS-AV700I DVD / RECEIVER – WITH FUSION LINK.     MS-CL602 6” MARINE CEILING MOUNT SPEAKERS x 2     MS-BT200 BLUETOOTH ADAPTER MODULE FOR SIRIUS PORT8.  APPLE TV

1.  SEALAND VACUUM TOILET (BONE COLOR)2.  WASH BASIN WITH MABLE COUNTERTOP3.  HOT & COLD WATER4.  FAUCET AND FITTINGS5.  MIRROR AND MIRRORED CEILING6.  SEPARATE SHOWER COMPARTMENT W/LACQUER FINISH7.  AC DOUBLE SOCKET WITH GFI8.  LACQUER FINISH ABOVE BASIN COUNTERTOP9.  VENEER FINISH BELOW BASIN COUNTERTOP10. EXTRACTOR FAN11. LED CEILING LIGHTS 24V12. MARBLE FLOOR

1.  DESK AND OVERHEAD STORAGE2.  HANGING CLOSET3.  CONCEALED SHELVES/STORAGE4.  LED CEILING LIGHTS 24V x 25.  HANGING LOCKER6.  FUSION STEREO SYSTEM     MS-RA205 RECEIVER / MEDIA PLAYER WITH FULL IPOD / IPHONE CONTROL     MS-CL602 6” MARINE CEILING MOUNT SPEAKERS x 2     MS-BT200 BLUETOOTH ADAPTER MODULE FOR SIRIUS PORT

1. LED CEILING LIGHTS 24V2. AC DOUBLE SOCKET3. U-LINE CO29B03 ICEMAKER4. VIZIO 24” CLASS E241I-B1 SMART TV5. FUSION STEREO SYSTEM    MS-AV700I DVD / RECEIVER – WITH FUSION LINK.    MS-CL602 6” MARINE CEILING MOUNT SPEAKERS x 4    MS-BT200 BLUETOOTH ADAPTER MODULE FOR SIRIUS PORT6. APPLE TV

70' JOHNSON SKYLOUNGE (New Construction)Please note, this is an unbuilt new construction project which has not yet been started.Listing broker has a list of popular options and prices, however, the standard equipment list above is very complete! Completion time is approximately 9-12 months depending on other yard projects.**OPTIONS UPON REQUEST** **ALL SPECIFICATIONS SUBJECT TO CHANGE WITHOUT NOTICE **Price FOB Taiwan. No US Tariff or Duty are included in the price.Since this is a new build offering, all photos are of previous projects. Exact layout, wood and stone selection are buyer's choice.
