2028 Hargrave Raised Pilothouse

PRODUCTION ORDER DETAILED SPECIFICATIONS: - Section 12" Deckfills for fuel and water600 Gallon Stainless Steel Water TankV-Shaped Keel w/ Longitudinal stringersFiberglass hand-laid hull & stringers vacuum bagged w/foam core reinforcementStringers bonded to hull encapsulated in several layers of glass cloth & resinDeck & superstructure w/ foam-cored reinforcement under the fiberglass FRP BulkheadsInterior structural components bonded to hull including bulkheads and framesFiberglass swim platform w/ ladderAll handrails, stanchions, and fittings are made of stainless steel 316 alloy1 1/2" Stainless Steel handrail w/ 1 1/4" stanchionsStainless steel cleats (8) the 2 cleats on the aft deck to tow 7000lb boatStainless steel 316 plow anchor (150lb), w/ 300' chain and Nilsson V3500 24 volt windlassStainless Steel frame hatch on foredeck w/ grey Lexan coverBuilt-in handheld shower on the swim platform4" stainless steel shafts Aquamet 225 Blade endplate KCA propellersZincs on shafts, rudders, and transom as neededMain bronze struts for 4" shaftFRP stern tube for 4" shaftsEmergency tillerStainless steel rudders  Fiberglass engine beds, bonded to hull w/ load distributed on steel channelsSound and heat insulation in Engine room bulkhead forward, aft and ceilingEasy access to all helm dashboard controls and gaugesRemote windlass operation from FlybridgeRacor 1000 FG fuel filter/water separator for each engineHydraulic Bow Thruster HPS-38hpHydraulic steering by Hynautic, adaptable to auto-pilotEngine Alarm System for low pressure & high temperature supplied by CAT24v lights (4) and (2) 110v power receptacles in Engine room Custom underwater engine exhaust w/idle by-pass100 Gallon Holding Tank w/ indicator and Headhunter waste treatment center 200gpdFreshwater filling faucet in the Engine room220v,110v and 60Hz Electrical SystemColor-coded wiring throughout to ABYC standardHelm Console with electronics as specifiedRule Sump Pumps (5) with acrylic coversY-Valve for dockside pump-out of holding tank(8) 200 amp/hr batteries for engine & ship power(3) Professional Mariner battery chargersSeparate 120 amp/hr batteries for generatorsAll batteries in FRP battery boxesMain electrical panel w/ separate AC Power control and circuit breaker panel110-volt duplex receptacles located throughout the vessel, including the engine roomIndirect rope lighting under valances in salon, staterooms, and galleyItalian door handle package (chrome)Push/Pull German latches (chrome)A removable white vinyl headliner panel systemRecessed Tray ceiling in the salon and over the dining areaLights in closets on micro switchesCantaloupe 24v ceiling lights (chrome)Dual track segmented curtains or Roman Shades in each stateroom, main salon & galleyBed on a pneumatic lift in Master and VIPLayout per owner approved drawingsLarge Storage areas forward deckBoat panel indicatorGranite countertop in the galleyMarble or Granite countertop in all bathroomsFull Walk-in Shower or Tub in masterStainless steel aft deck door frameBlack Textile front window covers for flybridge windowsFlybridge Vinyl seat coversHelm on Fly Bridge and L shaped settee(3) Freeman HatchesLexan hatch from the aft deck to Fly Bridge deckFull Caterpillar instruments at the helm (Tach/Oil Pressure/Engine Temp/TransPressure/Hrs)City water inlets (1)TV / telephone inlet (1)Add (1) city water inlet and (1) TV / telephone inlet in FRP cabinet at forward port bow deckFreshwater washdown (3) three locations - Bow/aft deck / Flybridge2 primer/sealer and 2 coats Black bottom paintSea Chest and Groco valvesWhite perforated insulation panels in Engine Room(3) Windshield wipers with blades Exalto and wash system100 AMP Galvanic Isolator x 2Upgrade to (7) Rule 3700 Bilge pumpCustom FRP Oval portlights x 14 (13.8" x 28.55", 2 fixed and 2 openable)Wet locker with drain and shelves access via Portside door from Port HallwayAdd (1) Freeman sliding door to Starboard side deckMECHANICAL EQUIPMENT – Section 2Upgrade to Aeroquip fuel hoseStainless Steel 304 pipes including fuel transfer, fuel fill, and fuel vent pipes forward of the Engine RoomTwo (2) 40 kW 60 Hz Northern Lights generators w/Soundshield and Start-Up Add second steering pump on the engine Additional sound insulation in the wall between VIP & Guest StateroomsAdditional sound insulation between the engine room and Guest StateroomsMastervolt Battery Charger 30AMP 12V + 30AMP 24V+ 80AMP(2) 100 AMP Mastervolt AC/DC light transformer 110/24VDouble insulate the engine roomWatertight door to engine room with backlit Hargrave nameWatertight bulkheads in the engine roomNaiad stabilizer system Model 360 with 12 sq. ft. fin w/Datum control Double stabilizer & bow thruster backup pump on the back of port & starboard engineUpgrade to 16LHT 62hp hydraulic bow thrusterLaminated hull fairing partsAdd hydraulic noise suppressors for Naiad thruster & stabilizer system4000 Gallons of fuel capacity (4) Delta-T Filters and Delta-T Fans Algae X fuel filter system x 2Double Racor filters on main enginesEngine room Sea Fire w/manual pulls FM 200Glendinning w/1 remote (3) fixed stations and bow and stern thruster controls at each station,and a power on-off switch at each station for thruster(1) Jabsco 6050-0003 AC bilge pumps on Engine Room floor with plumbing, (4) pickup and overboard dischargeOil change Reverso oil pumpFuel change Oberdorfer oil pump w/ Fillrite flow meter100 amp Cablemaster systems with 125’ cord out stern with easy access to breakers when they tripHot water circulating pumpCruiseair Chilled Water System with a total of 12 Tons with soft starts & DC air handlersAdd Cruiseair Fresh Air Makeup System with one AU24HVZ-FC-1.5KW Unit with control boxCorner Hawsers w/RollersSpurs Shaft line cutters for 4" shaftAdd Stern Cleats to swim platformTide Seal Marine dripless shaft logs & rudder post Provide watermaker through-hull and breaker 220 voltProvide wiring and support for davitKahlenberg D-OA Stack Trumpet Air HornAdd 1 Newmar 50 amp dc24 12volt converterRun wires for the monitor, 4 cameras and 1 controllerMagnetic compass 5" in the upper helmSecurity breaker switch for AC powerInstall US-supplied ACME transformers with USA supplied booster switch to be located under the gens for easy access to booster switchSafety rails around twin engines in ERTwo Additional Fluorescent lights in Engine RoomSeaFire Smoke Detection and Alarm System(12) CO Detectors combining to SeaFire Detection System (2) Torrid vertical 40 US Gallons water heater in white finishWater Drop Exhaust to generatorsMufflers for Main Engine idle by-passUpgrade the freshwater system to (2) AQX-230 super silent constant pressure system pump and mounting brackets for (2) pumpsAdd (1) additional 200 US gallon capacity Stainless Steel freshwater tankAdd freshwater filtersAdd two (2) Maxwell Stern VC200 DC24V electric Capstan with a footswitch on the bow deckINTERIOR EQUIPMENT: - Section 3Walnut wood interior and some painted surfacesInstall owner supplied wall upholsteryStandard headliner with foam backing throughout the boatVimar switches plus (12) dimmersAdditional decorator custom pillows (25)(7) Headhunter toiletsAwl-Grip finish FRP shower walls (5) stateroomsMarble Foyer floorTV lift recessed in the floor in Main SalonPainted wood trim for ceiling soffit in Dining Area and Main SalonMarble tops for the Forward, Port and Starboard Dining Consoles in Main SalonClear acrylic shelves in china cabinet in Main Salon(2) Silver flake decorative art glass backlight (dimmable) panel with frame for the Forward wall ofDining Area in Main SalonMirror Ceiling in DayheadFull Height Marble backsplash on the Forward and Aft walls next to Sink Counter in DayheadElysium Growing Fancy White Series Roman tile flooring in DayheadMarble wall behind the toilet in DayheadMarble cooktop backsplash in Galley(8) Corner drawer pulls in GalleyAll drawers constructed with full sides and full pull out extensions in GalleyAdd Stainless Steel handrails next to the stairway to Flybridge from the PilothouseBrushed Aluminum M2022 Formica in Lower Foyer on wall upholstery in Pilothouse and Port Hallway outboard and inboard(3) drawers under Pilothouse seatingCustom ceiling soffit in Master StateroomMarble Nightstand tops in Master StateroomTwo (2) hanging legal size file folder cabinets in Master StateroomAngled shoe racks in Master StateroomPocket Door to access Master HeadMarble Shower walls and floor in MasterMarble bathroom floor in VIPMarble bathroom floor in Port GuestMarble bathroom floor in Starboard GuestMarble shower seat in VIPMarble shower seat in Port Guest Marble shower seat in Starboard GuestFrameless glass shower door in VIP, Port and Starboard Guest bathroomsGrohe Rainshower F-Series 27468000 Shower System with Chrome Rain Head (flush mount) in MasterKohler Invigoration Series K-5525-NA Steam Unit in Master Grohe Allure - M 1938700A Chrome Sink Faucet (Wall mount single lever) in MasterGrohe Eurocube - M 23670000 Chrome Sink Faucet in VIPCR Laurence MT 18" x 18" Chrome Shower door pull handle/Towel Bar in Port and Starboard Guestsand Master (6" Pull Handle /18" Towel Bar)Gatco Elevate 4050 Chrome Towel Bar in Master (24" Towel Bar)Gatco Square Modern 1488 Chrome Toilet Brush Holder in VIP, Port, and Starboard Guest, Master, Captain and Crew HeadGatco Elevate Minimalist 4057 Chrome Towel Rack in MasterGinger Splashable 504L large corner basket Chrome shampoo caddy in Master(8) Stainless Steel Rails - lift out style for a shelf in Port and Starboard Guest Staterooms andStarboard Guest BathroomFrosted glass of Porthole in Port and Starboard Guest and Master60" X 80" X 8" Queen mattress in VIP30" X 78" X 8" Twin mattress in Port Guest60" X 78" X 8" King Mattress in Starboard Guest76" X 80" X 6" Mattress in MasterPneumatic lift in Port and Starboard GuestPneumatic lift in Captain Add a sliding mechanism to allow (1) single bed to slide in Port Guest CabinTV on the inboard wall in Crew LoungeFormica Countertop in Crew LoungeA lift-up Storage area in Crew CabinAdd (1) sliding pocket door EXTERIOR EQUIPMENT: - Section 4Hard Top with a Hargrave designed mast for electronicsFloodlights under radar arch x 2Extra 4" offset and 2 3/8” stainless steel oval hull banding w/wooden insert(6) "U" shape stanchions at the swim platformEnclosed FRP bow w/seat and non-skid finish for storage on bowAft deck bench seatingAft deck teak chairs (6)Aft deck teak table with gloss teak top and sliding mechanism (3) Swing out bar stools with swing are stool base at Aft DeckCustom Bar at Aft DeckCustom GRP spiral stairway to access Flybridge and Aft crew area from aft deck with a weather proof door and stainless steel railsUpgrade to larger handrails for aft deck stairway to access Flybridge(2) Handrails for step access to Boat deckCustom FRP Bar for Fridge / Freezer on Flybridge(2) Additional Bar stools for bar on Flybridge (1) Custom FRPcabinet with seating on aft Fly Bridge Port helmsman seat with a cushion on Flybridge(1) Stainless Steel footrest for settee on FlybridgeAdd (1) additional coffee table on stainless steel support on Flybridge(2) Sliding mechanisms for tables on FlybridgeCustom Sunbed with hatch to access storage underTV cable outlets x 3 located Aft Deck, Flybridge and helm areasAPPLIANCES: - Section 5Lower Foyer :GE WCVH4800KWW White Frontload WasherGE DCVH480EKWW White Frontload DryerCrew LoungeGE WCVH4800KWW White Frontload WasherGE DCVH480EKWW White Frontload DryerU-Line U-1215RS-00B Stainless Steel Refrigerator GE JES1072SHSS White MicrowaveFranke KBX110-8 Stainless Steel SinkGrohe Europlus 32946002 Chrome Sink FaucetGalley(2) Sub-Zero BI30U/S/TH Stainless Steel Refrigerator/Freezer (over and under)Dual install kit with pro louvered grill for Sub-Zero BI30UGE CP9530SJSS Black Cooktop (Rotary knob/not induction)GE PT7050SFSS Stainless Steel Oven (Convection & traditional bake)GE PVM9179SKSS Stainless Steel Microwave (Convection/duct outside)Fisher Paykel DD24DZX9_N Stainless Steel DishwasherGE UCG1680LSS Stainless Steel Trash CompactorHoshizaki AM50BAJ Stainless Steel Ice Maker with drain pumpFranke KBX11028 Stainless Steel SinkFranke KB28-36S Stainless Steel Sink gird drain rack (bottom grid)Franke KB28-31S Stainless Steel Sink gird drain rack (shelf grid)Blanco Altura 442207 Chrome Sink FaucetGE GFC720V Black disposal with MT951 Polished Chrome SwitchSalonEdgestar CWR262DZ Wine CoolerAft DeckHoshizaki AM50BAJ Stainless Steel Ice Maker with a drain pumpU-Line U-1215RS-00B Stainless Steel Refrigerator Elkay DXUH1210 Stainless Steel SinkScandvik 16006 Chrome Sink Faucet (folding faucet)Scandvik 14124 White shower box with sprayer and 13" hoseScandvik 10650 Elbow shower holder (USA install)Scandvik 10260 MountFlybridgeU-Line 1224RSOD-13A Stainless Steel Refrigerator (with lock)Hoshizaki AM50BAJ Stainless Steel Ice Maker with a drain pumpSub-Zero ID-24RO Refrigerator Drawer panel overlay (white fiberglass)Sub-Zero 7025230 Stainless Steel tubular handles(2) Frigibar Skipper white Freezer/Refrigerator (5 cubic feet)(2) Frigibar dual controlElkay DXUH1210 Stainless Steel SinkScandvik CANDVIK 16006 Chrome Sink Faucet (folding faucet)AUDIO VISUAL EQUIPMENT PACKAGE: - Section 6TV EquipmentTracVision HD7-USA for DirecTV mounted at MastKVH HD7/HD11 TracVision Expansion Kit - 16 TunersEdson 6' Vertical Vision Mount for KVH HD7Concord TV Distribution BoardFlybridgeFusion MS-RA770 A[p;;p 4.3" Capacitive Touch Glass LCD Color Display AM/FM Bluetooth/ Wi-Fi Audio Streaming/ Digital Optical Input/ USB AudioJL Audio M770-CCX-CG-WH M Series 7.7" Marine Cockpit Coaxial System x 2Aft DeckFusion MS-RA770 A[p;;p 4.3" Capacitive Touch Glass LCD Color Display AM/FM Bluetooth/ Wi-Fi Audio Streaming/ Digital Optical Input/ USB AudioJL Audio M770-CCX-CG-WH M Series 7.7" Marine Cockpit Coaxial System x 2Main SalonSamsung UN75NU800 75" Premium Smart 4K UHD TV Motivated Design Pop Up Lift + RemoteLarge TV Mount Binary Digital - Analog ConverterSonos PlaybarSonos Wall Mount PlaybarSonos SubDirecTV HR24 DVR Satellite Receiver with RemoteApple TV 4K 64GBSmartPro Line-Interactive UPS 1U RackNiles RCA-HT2 KitGalleySamsung UN40NU7100 40" Smart 4K UHD TVLarge TV Mount DirecTV HR24 DVR Satellite Receiver with RemoteTripplite SmartPro Line-Interactive UPS 1 U RackMaster StateroomSamsung UN50NU7100 50" LED-LCD TVLarge TV Mount Binary Digital - Analog ConverterSonos PlaybarSonos Wall Mount PlaybarNiles RCA-HT2 KitDirecTV HR24 DVR Satellite Receiver with RemoteApple TV 4K 64GBPort GuestSamsung UN40NU7100 40" Smart 4K UHD TVLarge TV Mount DirecTV HR24 DVR Satellite Receiver with RemoteStarboard GuestSamsung UN40NU7100 40" Smart 4K UHD TVLarge TV Mount DirecTV HR24 DVR Satellite Receiver with RemoteVIP Forward GuestSamsung UN40NU7100 40" Smart 4K UHD TVLarge TV Mount DirecTV HR24 DVR Satellite Receiver with RemoteCrew CabinHDTV LED TV - 19"Small TV MountHD Satellite Receiver with RemoteCaptain CabinLG 24" Class HD Smart LED TV with Built-In Wi-Fi & Ethernet ConnectivitySmall TV Mount DirecTV HR24 DVR Satellite Receiver with RemoteBattery Backup UPSNAVIGATION EQUIPMENT PACKAGE: - Section 7Radars/ChartplottersAxiom XL 19 - 18.5" Multifunction Display Kit (includes RCR-SD, Alarm and cable) x 2 mounted at PilothouseAxiom XL 19 Rear Mount Kit x 2 mounted at PilothouseRMK-10 Portrait I Landscape Keypad Remote Control System mounted at PilothouseAuxin XL - 16 - 16.5" Multifunction Display Kit (includes RCR-SD, Alarm, and cable) x 2 mounted at FlybridgeAxiom XL 16 Rear Mount Kit x 2 mounted at FlybridgeRMK-10 Portrait I Landscape Keypad Remote Control System mounted at FlybridgeMagnum 12kW with 6ft Open Array and 15m RayNet Radar CableMagnum 4kW with 4ft Open Array and 15m RayNet Radar CableRaystar 150 GPS with Pole MountAIS SystemAIS700 Class B with Splitter500 Gold Series, 8ft 6dB Gain Marine VHFVHF SystemRay90 VHF Black Box (includes Wired Handset, Passive Speaker and cable) x 2 mounted1 at Flybridge and 1 at PilothouseRay90 Wired 2nd Station Kit (includes Passive Speaker and Raymic Wired Handset x 2mounted 1 at Flybridge and 7 at PilothousePA-60/40 Hailer Horn x 2532-VW 500 Gold Series, 16ft 10dB Gain Marine VHFDepthsounderCP370 ClearPulse 1KW Sonar ModuleAirmar Bronze B260 D/T Broadband Through Hull StemDepth/ Speed/ Temp/ WindI70s System Pack Colour Instrument & Wind, DST TransducersI70s Multifunction Colour DisplayDST800 Through Hull Depth/ Speed/ Temperature Smart TransducerRaystar 150 BPS with Pole MountXM Weather SystemSR150 SiriusXM Weather Receiver with Antenna and cableAutopilot SystemEV-400 Power Autopilot with p70Rs Control Head and ACU-400, EV1 Sensor Core, EV1 Cabling Kit (suitable for Type 2 & 3 drives)P70Rs Autopilot Control Head (power)Type 2/24v Hydraulic PumpCamerasCAM220 Eyeball CCTV Day and Night Video Camera x 4HS-5 Network Switch x 24G Cellular SystemMDS-242-A 4G LTE Advanced High-Speed Modem, Dual SIM Card SlotsDockside WI-FI SystemAN-7000 Dual-Band, High Power Marine Wi-FiSmartPro 120V 750VA 600W Line-Interactive Sine Wave UPS, 1U RackmountSX-24 Port Managed Switch with 8 PoE or Up to 4 PoE+MAP-7 Dual Band Marine Access Point x 8Searchlight1MM Remote Control HID Searchlight includes URP-102 Point Pad & Master Controller YB 9282.3 Point Pad Kit for Yacht BeamPlatinum + US Southeast BahamasUSA INSTALLED EQUIPMENT: – Section 8Safety Package - Life Jackets/Fenders/Fire Extinguishers/Dock Lines/Flares/Dual plug phone/TV cordLife RaftsQuick Lift 2500lb Davit (2) 1500 GPD BWD-Explorer Compact Watermaker(3) Stidd 500N Low Back "Slimline" Admiral ChairsUMT Sea Stairs Boarding LadderINTERIOR DECOR PACKAGE: - Section 9For detailed information on the interior please request the detailed designer summary describing carpeting, drapes, spreads, couches, chairs, settee, stools, sinks, bowls, fixtures, lighting, door hardware, switches, as well as the scope of services provided by Yacht Interiors by Shelley of Fort LauderdaleThis information was taken from the actual production order and the delivered vessels may contain equipment and accessories supplied by the owner and are not reflected in these specifications.
